Quick Details:

Product Name: Solar Panel

Model: VC670M66-H

Solar Cell: Mono

Solar Cell Array: 132pcs

Dimension: 2384 x 1303 x 35 mm

Net Weight: 35.5kg

Back Sheet: White

Certificate: CE, IEC61215, IEC61730

Protect Level: IP68

Feature and Benefits:

• Assembled with multi-busbar cells, reduce shading effect on the energy generation, lower risk of hot spot.

• Pass th test for weather resistance in harsh environments.

• Process opimization of high efficiency PERC solar cell and strict control on raw materials to ensure highly resistance against PID of PV module.

• Better mechanical loading tolerance with the test front side 5400pa and back side 2400pa.

• Series and parallel design, reduce the series resistance RS of module, reduce the loss of internal electrical performance, and improve the power generation capacity of whole system.

• Cutting solar cell technology, which significantly reduces string current and module damage, it is good choice for projects in high temperature areas.
