12V 100Ah AGM Solar Battery
  • 12V 100Ah AGM Solar Battery
  • 12V 100Ah AGM Solar Battery
  • 12V 100Ah AGM Solar Battery

12V 100Ah AGM Solar Battery

Lead Acid Battery-VHC series
Recommendation Rate:

12V100Ah battery, agm vrla battery, rechargeable solar battery

Quick Details:

Model Number:12VHC100(12V100Ah)

Dimension: 331*173*216*222

Certification:CE,UL,ISO14001,ISO9001

Weight:30kg

OEM:Availble

Terminal:RT(M8)

Color:Black or grey

Capacity:100Ah

Sealed Type:Seald

Battery Type: Maintenance Free

Usage: Photovoltaic systems, Renewable Energy Systems, Outdoor control Equipments, Electric Utilities, Solar/Wind/Hybrid power systems, DC power supply, Security and fire alarm systems, Emergency lighting systems


Lead Time:

Quantity(Pieces)

1 - 50000

>50000

Est. Time(working days)

25~35

To be negotiated


Features and Benefits:

12V 100Ah AGM VRLA Rechargeable Solar Battery

• Designed floating charging service life: 12 years (25ºC)

• Sealed and maintenance free operation

• Safety valve installation for explosion proof

• Low self-discharge characteristic

• Wide operating temperature range from 0ºC~40ºC

• Lead Aluminum calcium Tin alloy high energy, prevent corrosion

Specification:

NOMINAL VOLTAGE

: 12V

NOMINAL CPACITY(10hr)

: 100Ah

DIMENSIONS


TOTAL HEIGHT

:222mm ( 8.74 inches )

CONTAINER HEIGHT

:216mm ( 8.50 inches )

LENGTH

:331mm (13.03 inches)

WIDTH

:173mm ( 6.81 inches)

WEIGHT

: APPROX 30.0Kg ( 66.14 lbs)

CONTAINER MATERIAL

: UL94HB ABS


: UL94V-0 ABS

INTERNAL RESISTANCE ( 25°C,77°F)

: ~4.53mΩ

DISCHARGE CAPACITY UNDER DIFFERENT TEMPERATURES

40°C

: ~102%

25°C

: ~100%

0°C

: ~85%

“VHC” deep cycle series adopts advanced AGM valve regulated technology, for example: thick plate design, special grid alloy, special paste formula, high temperature curing technology...



The recovery performance from deep discharge is excellent. It is widely used for frequent deep cycle applications, especially for Solar, Wind and other renewable energy storage systems.



Applications:

• Uninterruptable Power Supply (UPS)
• Telecommunication
• Emergency lighting
• Fire alarm and security systems
• Medical appliance
• Solar applications
• Electronic test equipment
• Electronic measuring devices
• Geophysical devices
• Marine equipment



Our advantages:

1. Specialized in batteries field more than 20 years, has plenty experiences of manufacturing and exporting.

2. Good quality battery with reasonable price. Comprehensive product system to meet customers' needs.

3. Capable to custom make for our customers according to their requirements.
