WM-T 8502 Hybrid Inverter(MPPT) 5000W

WM-T PV inverter with controller
Recommendation Rate:

How to Use the Inverter?

1. Battery number and capacity should be configured according to the rated voltage of the solar power system or inverter;


2. We offer 3 optional working modes (transfer time≤4ms):

◆ Grid priority mode: When the grid and battery are connected to the inverter, grid will supply power to the loads directly after voltage being stabilized and charge batteries via inverter. When the grid is cut off, the battery will automatically continue to supply power via inverter.


◆ Energy saving mode: If the power of the connected AC loads is lower than 5% of the inverter's rated power, there will be no output from the inverter. Only the chip of inverter is working. The power consumption of the inverter is only 1~6W. The LCD shows the output voltage 0. If the power of the connected loads is over 5%, within 5S the inverter will automatically convert DC to AC to supply power for the loads . The LCD shows the output voltage.


◆ Battery priority mode: When the grid and battery are connected to the inverter, battery will supply power to the loads first. When battery capacity is not enough, the grid will continue to supply power automatically.

Quick Details:

Product Name: Hybrid Inverter(MPPT)

Model: WM-T 8502

Rated Power: 5000W

Rated Input: 220VAC, 1Φ+N+PE, 50Hz

Input Voltage Range: AC170V~275V

Rated Output: 220VAC, 1Φ+N+PE, 50Hz

Rated Battery Voltage: 48VDC

PV Max.Vol.: 150VDC

PV Max. Power: 3360W

PV Max.Charge Cur.: 60A


Product Certification:

CE、IEC


Application Area:

◆  Domestic appliance:fan,lamp,rice cooker, etc.

◇  Office equipment:computers, printers, etc.

◆  Electronic communications: DVD, monitoring devices, communication stations, etc.

◇  Electric tools: electric drill, punching machine, water pump, etc.

◆  Vehicle and ship equipment: ambulances, ships, traffic lights, etc.

◇  Emergency power supply: standby power supply


Feature:

◆ Pure sine wave output;

◇ Low frequency toroidal transformer lower loss;

◆ Intelligent LCD integration display;

◇ Built-in PWM or MPPT controller optional;

◆ AC charge current 0~30A adjustable, three working modes selectable;

◇ Peak power more than 3 times, full-automatic and perfect protection function;

◆ Added fault code query function, easy to monitor the operation in real time;

◇ Supports diesel or gasoline generator, adapt any tough electricity situation;

◆ Combine industrial and home usage, wall-mounted design, convenient installation.

Product Parameters
Specification
Model WM810283028502
Rated Power1000W3000W5000W
Peak Power(20ms)3000W9000W15000W
Start Motor1HP3HP4HP
Battery Voltage12/24VDC24/48VDC48VDC
Size(L*W*Hmm)500*300*140530*335*150
Packing Size(L*W*Hmm)565*395*225605*430*235
N.W.(kg)122024
G.W.(kg)(Carton Packing)13.521.526
Installation MethodWall-Mounted
Parameter
InputDC Input Voltage Range10.5-15VDC(Single battery voltage)
AC Input Voltage Range85VAC~138VAC / 170VAC~275VAC
AC Input Frequency Range45Hz~65Hz
Max AC charging current0~30A(Depends on model)
AC charging methodThree-stage (constant current, constant voltage, floating charge)
OutputEfficiency(Battery Mode)≥85%
Output Voltage(Battery Mode)110VAC±2%  / 220VAC±2%
Output Frequency(Battery Mode)50/60Hz±1%
Output Wave(Battery Mode)Pure Sine Wave
Efficiency(AC Mode)>99%
Output Voltage(AC Mode)110VAC±10%  / 220VAC±10%
Output Frequency(AC Mode)Tracking Automatically
Output waveform distortion
(Battery Mode)
≤3%(Linear load)
No load loss(Battery Mode)≤0.8% rated power
No load loss(AC Mode) ≤2% rated power( charger does not work in AC mode)
No load loss(Energy saving Mode)≤10W
Battery TypeVRLA BatteryCharge Voltage :14V; Float Voltage:13.8V(Single battery voltage)
Customize batteryCharging and discharging parameters of different types of batteries can be customized according to user requirements
 (charging and discharging parameters of different types of batteries can be set through the operation panel)
ProtectionBattery undervoltage alarmFactory default: 11V(Single battery voltage)
Battery undervoltage protectionFactory default: 10.5V(Single battery voltage)
Battery overvoltage alarmFactory default: 15V(Single battery voltage)
Battery overvoltage protectionFactory default: 17V(Single battery voltage)
Battery overvoltage recovery voltageFactory default: 14.5V(Single battery voltage)
Overload power protectionAutomatic protection (battery mode), circuit breaker or insurance (AC mode)
Inverter output short circuit protectionAutomatic protection (battery mode), circuit breaker or insurance (AC mode)
Temperature protection>90°C(Shut down output)
AlarmANormal working condition, buzzer has no alarm sound
BBuzzer sounds 4 times per second when battery failure, voltage abnormality, overload protection
CWhen the machine is turned on for the first time, the buzzer will prompt 5 when the machine is normal
Inside Solar controller
(Optional)
Charging ModeMPPT or PWM
Charging current10A~60A(PWM or MPPT)
PV Input Voltage RangePWM: 15V-44V(12V system); 30V-44V(24V system); 60V-88V(48V system)
MPPT: 15V-120V(12V system); 30V-120V(24V system); 60V-120V(48V system)
Max PV Input Voltage
(At the lowest temperature)
PWM: 50V(12V/24 system), 100V(48V system );   MPPT: 150V
Standby loss≤3W
Maximum conversion efficiency>95%
Working ModeBattery First/AC First/Saving Energy Mode
Transfer Time≤4ms
DisplayLCD
Thermal methodCooling fan in intelligent control
CommunicationRS232/RS485(Optional)
EnvironmentOperating temperature≤55dB
Storage temperature-10℃~40℃
Noise-15℃~60℃
Elevation2000m(More than derating)
Humidity0%~95% ,No condensation
Warranty1 year
Note: All specifications are subject to charge without prior notice
