4DSC4.8-203-200-1500-A/D Solar Submersible Pump

Solar Submersible Pump
Recommendation Rate:

Quick Details:

Product Name: Solar Pump (Submersible)

Model: 4DSC4.8-203-200-1500-A/D

Dimension: 795 x 100 mm

Net Weight: 12kg

Certificate: CE

IP Protection: IP68


Features and Benefits:

• Permanent magnet DC brushless synchronous motor.

• Brass or stainless steel outlet/connector/oil cylinder.

• Japanese NSK bearing.

• Alloy mechanical seal.

• Hi-precision and smoothness pump parts.

• Intelligent water shortage and water full protection.

• Hi-efficient solar power utilization MPPT controller

• Auto start and stop working.

• Frequency conversion technology.

• Multi-protection, to avoid high or low voltage / high or low temperature.

• Warranty: 2 years.



Specification:

Model4DSC4.8-203-200-1500-A/D
Max. head (M)203
Max. flow (L/H)4800
Voltage (AC)85-280
Voltage (DC)80-420
Power (W)1500
Pump Diameter (inch)4
Outlet Diameter (inch)1.25
Impeller MaterialStainless Steel
