SCPM70-16-220/300-2200 SOLAR SURFACE PUMP
Solar Surface Pump
Recommendation Rate：
FEATURES:
* High efficiency
* MPPT PV controller
* Multi-protections
* Long life
MAIN PARTS:
* Motor: Permanent magnetic synchronous brushless DC motor
* Pump head: Stainless stell & Cast iron
* Pump body: Stainless steel & Cast iron
* Motor body: Die-cast Aluminum
* Impeller: Stainless steel & Brass
* Bearing: NSK, Japan
SPECIFICATION:
| Model | SCPM70-16-220/300-2200 |
| Max. Flow | 70 M³/H |
| Max. Head | 16M |
| Power | 2200W |
| DC Voltage | 300V |
| AC Voltage | 220V |
| Inlet Diameter | 4 Inches |
| Outlet Diameter | 4 Inches |
| Solar Panel VOC Range | From 360V to 450V |
| Solar Panel Power | 3300W |
