12.8V 200Ah Maintenance Free Lifepo4 Lithium-ion Batteries
12.8V200Ah Lifepo4 Battery, Maintenance Free Lithium-ion Batteries
Features:
•Lithium Iron Phosphate (LiFePO4): the Safest Lithium Technology.
•Integrated Battery Management System(BMS).
•Bluetooth/RS485/RS232/SMBus/CANBus (Optional). SOC LED/LCD Indicator(Optional).
Performances:
•Long Cycle Life>2000cycles @100% DOD.
•High Density, High Discharge Current, High Temperature Range.
•Low Weight, Free Maintenance.
•Fast Charging.
•Environment Friendly.
Applications:
•Data Center UPS
•Telecom Backup Power
•Military Power Supply
•Solar Energy Storage System
•Solar Street LED Lightings
•Autonomously Guided Vehicles (AGVs)
•Industrial Robotics & Handling Equipment
•Aerial Work Platform
•Floor Cleaning Machines
•Power Tools, Lawn Mower
•Electric Bike & Motorcycles
•Electric Mobilities( E-scooters,Wheelchair)
•Golf Trolley & Golf Carts
•Medical Devices
•Electric Ships
•Passenger Vehicles
Battery Data Sheet
Electrical Parameters | |
Nominal Voltage | 12.8V |
Rated Capacity | 200Ah |
Energy | 2560Wh |
Resistance | ≤30mΩ |
Efficiency | 99% |
Cycle Life | >2000cycles @1C,100% DOD |
Self Discharge | 2% per Month |
Max. Modules in Series/Parallel | 4S/20P |
Mechanical Parameters | |
Dimension(L x W x H) | 522x 240x 224 mm |
20.6 x 9.4x 8.8" | |
Weight | 29.6kg(65.26lbs) |
Terminal Type | M8 |
Battery Housing | ABS, UL-94 V-0 |
Housing Protection | IP56 |
Cell Type-Chemistry | LiFePO4 Cylindrical Cell |
SOC Display(Optional) | LED/LCD Indicator |
Discharge Parameters | |
Continuous Discharge Current | 200A |
Pulse Discharge Current | 900A(5 seconds) |
Recommended Volt. Disconnect | 10V |
BMS Discharge Cut-off Voltage | 8V |
Reconnect Voltage | 9.2V |
Short Circuit Protection | 200~600 us |
Charge Parameters | |
Charge Method | CC-CV |
Charge Voltage | 14.4~14.8V |
Recommended Float Voltage | 13.8V |
Recommended Charge Current | 100A |
Maximum Charge Current | 200A |
BMS Charge Cut-off Voltage | 15.6V |
Temperature Parameters | |
Discharge Temperature | -30 to 60℃ (-22 to 140℉) |
Charge Temperature | 0 to 45℃ (32 to 113℉) |
Storage Temperature | -40 to 60℃(-40 to 140℉) |
BMS High Temperature Cut-off | 80℃(176℉) |
