Lead Acid Solar Gel UPS 12V150Ah Storage Battery
Lead Acid Battery, Solar Gel Storage Battery, 12V150Ah
Quick Details:
Model Number: 12GEL150(12V150Ah)
Dimension: 485*170*240*240
Certification: CE,UL,ISO14001,ISO9001
Weight: 44.3kg
OEM: Availble
Terminal: RT(M8)
Color: Black or grey
Capacity: 150Ah
Sealed Type: Seald
Battery Type: Maintenance Free
Usage: Photovoltaic systems, Renewable Energy Systems, Outdoor control Equipments, Electric Utilities, Solar/Wind/Hybrid power systems, DC power supply, Security and fire alarm systems, Emergency lighting systems
Lead Time:
Quantity(Pieces) | 1 - 50000 | >50000 |
Est. Time(working days) | 25~35 | To be negotiated |
Features and Benefits:
Lead Acid Solar Gel UPS 12V150Ah Storage Battery
• Designed floating charging service life: 15 years (25ºC)
• Safety valve installation for explosion proof ,Sealed and maintenance free operation
• By using strong grids, high purity lead and patented Gel electrolyte
• Extremely low self-discharge characteristic
• Wide operating temperature range from -20ºC~55ºC
• Lead Aluminum calcium Tin alloy high energy, prevent corrosion
Specification:
NOMINAL VOLTAGE | : 12V |
NOMINAL CPACITY(10hr) | : 150Ah |
DIMENSIONS | |
TOTAL HEIGHT | :240mm ( 9.45 inches ) |
CONTAINER HEIGHT | :240mm ( 9.45 inches ) |
LENGTH | :485mm (19.09 inches) |
WIDTH | :170mm ( 6.69 inches) |
WEIGHT | : APPROX 44.3Kg ( 97.46 lbs) |
CONTAINER MATERIAL | : UL94HB ABS |
: UL94V-0 ABS | |
INTERNAL RESISTANCE ( 25°C,77°F) | : ~3.10mΩ |
DISCHARGE CAPACITY UNDER DIFFERENT TEMPERATURES | |
40°C | : ~103% |
25°C | : ~100% |
0°C | : ~86% |
“GEL” deep cycle series adopts advanced AGM valve regulated technology, for example: thick plate design, special grid alloy, special paste formula, high temperature curing technology… and the unique Gel electrolyte technology which can solve the water loss problem and provide more wide temperature range -20℃~55℃. It is widely used for frequent deep cycle applications, especially for Solar Wind and other renewable energy storage systems.
Applications:
• DC power supply
• Photovoltaic systems
• UPS/EPS power supply
• Electrical devices & instruments
• Security and fire alarm systems
• Telecom stations and power stations
• Medical equipments
• Emergency lighting systems
Our advantages:
1. Specialized in batteries field more than 20 years, has plenty experiences of manufacturing and exporting.
2. Good quality battery with reasonable price. Comprehensive product system to meet customers' needs.
3. Capable to custom make for our customers according to their requirements.
